Paving Stone Lifter APSL – Description


General

When installing pavers, the Paving Stone Lifter saves time and reduces stress on the back and knees.  It can also be used with concrete, sandstone, slate, etc.  The safe lifting height recommended when using the Paving Stone Lifter is no more than 75mm (3”) to 125mm (5”) above the work area.

Feature

  • The head is constructed with heavy-duty aluminium.

  • A complete line of interchangeable heads is available in different sizes for lifting various types and sizes of materials.

  • Visual low vacuum alert.

Specifications




Metric
Imperial
Pad sizes
with W.L.L
276x176mm:
110kg
186x86mm:
28kg
10 7/8''x6 7/8'':
242.5 lbs
7 3/8''x3 3/8'':
62 lbs
Net weight16kg
35.3 lbs

Gross weight36 kg
79.4 lbs

Packaging dimensions
720 mm
420 mm
770 mm
28 3/8''
16 1/2''
30 1/4''

Battery information for the device

Battery capacity 24VDC-8Ah
Non-stop working time   4 hours

Motor information

Vacuum flow rate 38 liters/minute
Motor 24VDC - 2A
